This kit can be fitted with minimal alteration to an existing hydraulic control.
A proportional electro-valve controls the pilot line on the service corresponding to the directional valve of the hydraulic motor for the winch.
The objective is to stop the winch at a desired position independent of the operator.
Once this position is set, the winch will stop during the lifting operation protecting the mechanical assembly and offering additional safety to the operator.
Benefits:
1. Increased Safety: The system stops the winch at the pre-set position independently of the operator.
If any component of the electrical system is damaged the winch will stop.
2. Easy Set-up: The set-up can be made on the field with a touch screen display.
There are no tools required.
The touch screen display provides step by step instructions for the set-up.
3. Simple Installation: The SUN Proportional Valve can be installed on any directional control valve in the pilot line.
The electronic control box requires 24VDC power supply.
The encoder is IP66 Rated and has a 6 mm shaft.
The kit includes the coupling and the bell housing.
4. Long Service: There are no mechanical adjustments necessary.
The system can be custom configured to offer additional features including speed and control display, pressure or torque display, torque limitation or selection, electronic power limitation, and position display.
For more information contact enquiry@custom.com.au
