The SPEC Pak uses Anderson's UL recognized, low cost, ultra high mating life Powerpole contact system in a watertight connector body creating the "next generation" in high power interconnect solutions.
Features
IP67 rated housings
SPEC Pak housings accept up to 6 Anderson Powerpole 15/45A connectors in standard or finger-proof styles
Housings and connectors can be ordered separately or together
Rugged and reliable components
High amperage connection to 30A per contact, 45A if only outer 4 positions used
1000's of internal component configurations possibleUp to 10,000 mating cycles
Signal, power, and ground contacts available
Internal components available in multiple colours
Meets sealing requirements of UL50
Benefits
Housing design and materials protect electrical components from water, dust, and other environmental contaminants
Waterproof beyond IP67 requirements, when used with industry standard cable sealing glands
Same components will work with wire sizes from #10 to #24 AWG (0.25 to 4.0mm2) and all coloured housingsLong life - up to 10,000 mating cycles
Multiple contact versions to meet most power, ground and signal electrical needs
Finger-proof versions help prevent fingers (or probes) from accidentally touching live contacts, meet UL 1977 and EC/ IEC 60529 finger probe test
Housings can be colour coded to wires for ease of assembly
